Chapter 3 - System setup 3 - 21
3-7-3 Electrical specifications
3-7-3-1 Verification of the system’s voltage setting
Verify that the mains voltage specified for the unit is available on-site.
The voltage setting for the unit is found on a label near the Mains Power Circuit Breaker on the rear of
the system.
3-7-3-2 Electrical specifications for VIVID E9
In the table below, the electrical specifications for VIVID E9 includes monitor and on board peripherals.
The current drain will vary depending on the mains voltage.
• At 230 VAC the current may be up to 5 A.
• At 100 VAC the current may be up to 12 A.
WARNINGWARNING
CONNECTING A VIVID E9 UNIT TO THE WRONG VOLTAGE LEVEL WILL MOST LIKELY
DESTROY THE UNIT.
Figure 3-4 Mains Voltage Rating label
Table 3-12 Electrical specifications for VIVID E9
PART NUMBER DESCRIPTION VOLTAGE TOLERANCES
POWER
CONSUMPTION FREQUENCY
BT’12
GA000940 Vivid E9 4D Expert Option - 17” LCD
100-230 VAC ±10% 1100 W 50/60 Hz
GA000950 Vivid E9 4D Expert Option - 19” LCD
GA000945 Vivid E9 2D - 17” LCD
GA000955 Vivid E9 2D - 19” LCD
GB000040 Vivid E9 BT12 PRO Configuration 17” LCD
GB000050 Vivid E9 BT12 PRO Configuration 19” LCD
BT’11
GA000810 VIVID E9 4D Expert Option - 17” LCD
100-230 VAC ±10% 1100 W 50/60 Hz
GA000815 VIVID E9 4D Expert Option - 19” LCD
GA000830 VIVID E9 2D - 17” LCD
GA000835 VIVID E9 2D - 19” LCD
BT’09
GA000100 VIVID E9 (with 4D) - v108.x.x 100-230 VAC ±10% 1100 W 50/60 Hz
M o d e l :
G A 3 1 4 3 2 3 0 1
V A C
W
H z
V i v i d E 9
R E F
R E F
H 4 5 5 4 1 S D
# 1
# 2
G A 0 0 0 1 0 0
1 1 0 0
5 0 / 6 0
1 0 0 - 2 3 0
VERIFY THAT THE VOLTAGE ON THE
LABEL CORRESPONDS TO THE SITE’S
MAINS VOLTAGE
