GE Vivid E9

GE H EALTHCARE
D IRECTION GA091568, R EVISION 5 VIVID E9 S ERVICE M ANUAL
5 - 76 Section 5-9 - Back End Processor (BEP)
5-9-16 Graphics Adapter
5-9-16-1 General Description
The Graphics Adapter converts the display data to video signals for the LCD (Main) screen, for the LCD/
Touch screen and for the external video output on the rear of the VIVID E9.
5-9-16-2 Location in the Unit
The Graphics Adapter is located in the PCI Express slot (PCI Express x16) inside the BEP cabinet.
5-9-16-3 Input Signals
• Graphics data from the BEP (via the BEP’s motherboard).
5-9-16-4 Output Signals
• DVI to the LCD screen (main screen).
• Video to the external output on the rear of VIVID E9.
5-9-17 Internal Storage Devices
VIVID E9 has these internal storage devices:
• SATA (Serial ATA) Hard Disk Drive (HDD) inside the Back End Processor cabinet (size: 160 GB,
or more)
• CD/DVD drive available from front of VIVID E9. ONLY CD-R discs and DVD-R recordable discs are
supported.
• The optional DVR uses DVD+RW discs.
