GE H EALTHCARE
D IRECTION GA091568, R EVISION 5 VIVID E9 S ERVICE M ANUAL
8 - 262 Section 8-11 - Back End Processor (BEP) parts replacement
8-11-4 Graphics Adapter replacement
8-11-4-1 Overview
BT’12 scanners:
These Graphics Adapters may be used, depending on the VIVID E9 model and BEP model:
• BT’12 with BEP6 with 4D: Nvidia Quadro 410
• BT’12 with BEP6 without 4D: Video Bypass Board
• BT’12 with BEP5 with 4D: Nvidia Quadro 2000D
• BT’12 with BEP5 without 4D: Prolink Add 2 card
NOTE: On BEP6 without 4D, the graphics circuits (Intel® HD Graphics and Intel® Graphics Media
Accelerator) are included on the BEP’s motherboard. A Video Bypass Board is plugged into the
graphics port for signal routing purpose.
BT’11 scanners:
These Graphics Adapters are used, depending on the VIVID E9 BT’11 model.
• BT’11 with 4D: Nvidia Quadro FX1800 or Nvidia Quadro 2000D
• BT’11 without 4D: Prolink Add 2 card
BT’09 scanners:
These Graphics Adapters have been installed on VIVID E9 BT’09:
• ATI Fire GL V7200
• Nvidia Quadro FX1800
• Repaired scanners may have Nvidia Quadro 2000D

GE Vivid E9 Specifications

General

Power Requirements	100-240 VAC, 50/60 Hz
Display	High-resolution LCD monitor
Doppler Modes	Color Doppler, Pulsed Wave Doppler, Continuous Wave Doppler
3D/4D Imaging	Yes
Advanced Features	Speckle Reduction Imaging
Connectivity	DICOM, USB, Ethernet
Transducer Types	Linear Array
Operating Temperature	10°C to 40°C
Humidity Range	30% to 80% non-condensing
