2 - 2 Section 2-2 - General console requirements
Section 2-2
General console requirements
2-2-1 Console environmental requirements
2-2-1-1 If the unit is very cold or hot
2-2-1-2 Environmental specifications for VIVID E9 scanners
Temperature Limits:
•Operation:
10 to 35 ºC (50 to 95 ºF)
• Storage and Transport:
-20 to 60 ºC (-4 to 140 ºF)
Humidity Limits:
•Operation:
30 - 60% rH non-condensing
• Storage and Transport:
30 - 95% rH non-condensing
Air Pressure Limits:
•Operation:
700-1060 hPa
• Storage and Transport:
700-1060 hPa
Heat Dissipation:
• 3800 BTU/h
CAUTION
IF THE UNIT IS VERY COLD OR HOT, DO NOT TURN ON ITS POWER UNTIL IT HAS HAD A
CHANCE TO ACCLIMATE TO ITS OPERATING ENVIRONMENT.
Table 2-1 VIVID E9 Acclimate Time
o
C
-40-35-30-25-20-15-10-5 0 5 10152025303540455055606570
o
F
-40 -31 -22 -13 -4 5 14 23 32 41 50 59 68 77 86 95 104 113 122 131 140 149 158
Hrs 2018161412108642000000024681012

GE Vivid E9 Specifications

General

Power Requirements	100-240 VAC, 50/60 Hz
Display	High-resolution LCD monitor
Doppler Modes	Color Doppler, Pulsed Wave Doppler, Continuous Wave Doppler
3D/4D Imaging	Yes
Advanced Features	Speckle Reduction Imaging
Connectivity	DICOM, USB, Ethernet
Transducer Types	Linear Array
Operating Temperature	10°C to 40°C
Humidity Range	30% to 80% non-condensing
