D IRECTION GA091568, R EVISION 5 VIVID E9 S ERVICE M ANUAL
Chapter 5 - Components and functions (theory) 5 - 55
5-9-6 BEP description
5-9-6-1 The EMC Enclosure House
• A power supply for local voltages
• A motherboard with RAM, a processor and PCI connectors for extension cards
• An I/O board on the rear of the BEP
5-9-6-2 Outside the EMC Enclosure House
• Front Panel with status lights (LEDs) for hard disk activity and network speed (upper LED) and
network activity (lower LED).
• Patient I/O with AUX, Phono and ECG connectors.
• BEP I/O Board.
Figure 5-40 Front Panel
