8 - 146 Section 8-6 - Top Console Parts Replacement
8-6-23-3 Alphanumeric Keyboard Assembly removal procedure (cont’d)
3.) Tilt down the Alphanumeric Keyboard assembly. If you are afraid to use the needed force, you may
use a flat blade screwdriver to unlock the two locks illustrated in Figure 8-156 "Alphanumeric
Keyboard seen from below" on page 8-145.
4.) Move the Alphanumeric Keyboard assembly so it un-gage, then lift it away.
8-6-23-4 Alphanumeric Keyboard assembly installation procedure
Follow these steps to install the Alphanumeric Keyboard assembly:
1.) Install the Alphanumeric Keyboard assembly in the “hinges” on the rail.
2.) Tilt the Alphanumeric Keyboard assembly up so it locks in horizontal position.
3.) Connect the ESD cable.
4.) Connect the cable to the connector on the rear of the Alphanumeric Keyboard assembly.
