D IRECTION GA091568, R EVISION 5 VIVID E9 S ERVICE M ANUAL
Chapter 8 - Replacement procedures 8 - 167
8-6-33-2 Palm Rest ASSY removal
Follow these steps to remove the Palm Rest:
1.) Release the lock mechanisms securing the Palm Rest ASSY.
2.) Remove the Palm Rest ASSY.
8-6-33-3 Palm Rest ASSY installation
Follow these steps to install the Palm Rest ASSY:
1.) Ensure the XYZ Buttons cable runs along the lower tray cable channel so that the cable is not
pinched when the Palm Rest is replaced.
2.) Replace the Palm Rest ASSY.
3.) Install Handle Left Top and Handle Right Top.
4.) Install the lock mechanisms securing the Palm Rest Cover.
5.) Replace the Lower Operator Panel.
6.) Replace the Upper Operator Panel.
