8 - 286 Section 8-11 - Back End Processor (BEP) parts replacement
8-11-11-3 DVI to Samtec Jumper (Flex) installation
Follow these steps to install the DVI to Samtec Jumper (Flex):
1.) Install the DVI to Samtec Jumper(s) (Flex(es))
- 4D with DVR:
- Install the DVI to Samtec Jumper (Flex) between CN DV12 on the MBD and DVI OUT
on the DVR board.
- 4D without DVR:
- Install the DVI to Samtec Jumper (Flex) between CN DV12 on the MBD and the
Graphics Adapter.
- 2D with DVR:
1.) Install one DVI to Samtec Jumper (Flex) between CN DV12 on the MBD and DVI OUT
on the DVR board.
2.) Install one DVI to Samtec Jumper (Flex) between CN DV11 on the MBD and DVI IN on
the DVR board.
2.) Install the BEP Cover.
3.) Install the Left Side Cover.
