D IRECTION GA091568, R EVISION 5 VIVID E9 S ERVICE M ANUAL
Chapter 2 - Site preparations 2 - 5
2-2-2-2 Electrical requirements for VIVID E9
In the table below, the electrical specifications for VIVID E9 includes monitor and on board peripherals.
The current drain will vary depending on the mains voltage.
• At 230 VAC the current may be up to 5 A.
• At 100 VAC the current may be up to 12 A.
2-2-2-3 Site circuit breaker
It is recommended that the branch circuit breaker for the unit be readily accessible.
2-2-2-4 Site power outlets
A dedicated AC power outlet must be within reach of the unit without extension cords. Other outlets
adequate for the external peripherals, medical and test equipment needed to support this unit must also
be present within 1 m (3.2 ft.) of the unit. Electrical installation must meet all current local, state, and
national electrical codes.
2-2-2-5 Unit power plug
If the unit arrives without a power plug, or with the wrong plug, you must contact your GE dealer or the
installation engineer must supply what is locally required.
Table 2-2 Electrical specifications for VIVID E9
PART NUMBER DESCRIPTION VOLTAGE TOLERANCES
POWER
CONSUMPTION FREQUENCY
BT’12
GA000940 Vivid E9 4D Expert Option - 17” LCD
100-230 VAC ±10% 1100 W 50/60 Hz
GA000950 Vivid E9 4D Expert Option - 19” LCD
GA000945 Vivid E9 2D - 17” LCD
GA000955 Vivid E9 2D - 19” LCD
GB000040 Vivid E9 BT12 PRO Configuration 17” LCD
GB000050 Vivid E9 BT12 PRO Configuration 19” LCD
BT’11
GA000810 VIVID E9 4D Expert Option - 17” LCD
100-230 VAC ±10% 1100 W 50/60 Hz
GA000815 VIVID E9 4D Expert Option - 19” LCD
GA000830 VIVID E9 2D - 17” LCD
GA000835 VIVID E9 2D - 19” LCD
BT’09
GA000100 VIVID E9 (with 4D) - v108.x.x 100-230 VAC ±10% 1100 W 50/60 Hz
CAUTION
POWER OUTAGE MAY OCCUR. THE VIVID E9 SCANNER REQUIRES A DEDICATED SINGLE
BRANCH CIRCUIT. TO AVOID CIRCUIT OVERLOAD AND POSSIBLE LOSS OF CRITICAL CARE
EQUIPMENT, MAKE SURE YOU DO NOT HAVE ANY OTHER EQUIPMENT OPERATING ON THE
SAME CIRCUIT.
