F E

000291

10. Check that the value (F) rises to the set value.

11. Log off CS 1000.

12. Reset the temperature sensors.

7 REPAIRS AND ADJUSTMENT

TECHNICAL MANUAL GETINGE WD15 CLARO 113 (128)

<Doc_TEC><Doc_6001396902><Rev.I><Lang_en>
