GDS3710 User Manual
Version 1.0.7.8
2. Open door: Connect a switch to open door from inside.
If Digital Input port is connected to a switch, it will not work during the
time of power outage, device booting or firmware upgrading.
Digit Input 2 Open Door
Option
When Digital Input is set to Open door then user can select the doors
to be affected when Alarm IN 2 is triggered.
• If set to Normal Open: Configured alarm will be triggered when
Digital Input Status switch from Close to Open.
• If set to Normal Close: Configured alarm will be triggered when
Digital Input Status switch from Open to Close.
By default, Input Digit 2 Status is “Disabled”.
Selects the predefined Alarm Schedule.
Select Alarm Action Profile 2
Selects the predefined Alarm Action for Profile 2.
Select the duration of the alarm output: 5/10/15/20/25/30 seconds.
This option is hidden when ALMOUT1 Feature is set to Open Door.
Enable Silent Alarm Mode
If Silently Alarm Mode is enabled, GDS3710 will disable alarm sound and background light for specified
alarms types (Digital Input, Motion Detection…) when they are triggered.
Note: This option affects only alarm sound/light, other actions will still be applied.
Table 24: Silently Alarm Mode
Enable/Disable silent alarm mode.
When the silently alarm mode is enabled, users can specify to which
alarm options the silently mode will be applied to.
The available options are: Digital Input, Motion Detection, Tamper
Alarm, and Password Error.
Hostage Code
Hostage password can be used in a critical situation for instance a kidnaping or an emergency, users need
to enter the following sequence to trigger the actions set for the Hostage Mode: “* HostagePassword #”.
Table 25: Hostage Code Alarm
Enable/Disable the Hostage password mode.
Configures the password for the hostage mode.
Select Alarm Action Profile
Select the Alarm action to be taken when the hostage password is
typed on the GDS3710 keypad.
Note: No sound alarm will be triggered in this mode.
