P a g e | 110
GDS3710 User Manual
Version 1.0.7.8
Figure 84: Picture Storage Settings
Notes:
• If the connection to the FTP server is successful, a “.txt” file containing a success message will be
uploaded to the FTP server. And the following message will pop up on the webGUI
.
• Central Storage will use GDS Manager built-in FTP server to store screenshots.
FTP Filenames
When setting up FTP server to store snapshots (when doorbell pressed, or door Unlocked), the GDS will
create folder with device MAC address (if multiple GDS3710s are sending snapshots to same FTP server).
In EACH folder based on MAC address or device, the file folder will be created by DATE, to organize and
classify the snapshots received during different DATE for easy analysis.
In EACH folder classified with DATE, the snapshot file name is based on following naming schema:
Table 33: FTP Filenames
FTP Filename with
Description
CARD
Meaning that open door operation is using RFID card.
LPIN (Local PIN)
Meaning that open door operation is via Local PIN (Private PIN, or Unified PIN,
or Guest PIN).
RPIN (Remote PIN)
Meaning that open door operation is via remote PIN or DTMF PIN. (by local or
remote SIP extensions, or GS_Wave/Cellphone, or GDSManager if installed in
operation).
