GDS3710 User Manual
Version 1.0.7.8
• If MJPEG is selected, reduce the frame rate to the minimal value to save bandwidth and get better
image.
• Grandstream GDS3710 provides three video streams, users can use them with flexibility. For
example, the high-resolution stream for local recording, another low or high resolution for SIP video
phone call or remote smartphone monitoring application, or vice versa depending application
scenarios.
• Use below link to calculate bandwidth and storage before installation
http://www.grandstream.com/support/tools/bandwidth-storage-calc
Retrieving Video Streams
• To retrieve video stream via RTSP, users can use the following format :
rtsp://admin:password@IP_GDS3710:Port/X where X=0,4,8 for 1
st
, 2
nd
, 3
rd
streams respectively
• To retrieve MJPEG video stream via http, users can use the following format:
http(s)://admin:password@IP:port/jpeg/stream=X (X=Stream channel 0,1,2)
Important note: MJPEG is uncompressed video and it can consume a lot of bandwidth and hardware
resources, it is recommended to use it while taking this into consideration that it might slow down network
and device.
OSD Settings
OSD Settings (On Screen Display) allow the users to Display time stamp and text on the video screen.
Figure 71: OSD Settings Page
Table 19: OSD Settings
Display Time
When checked, time will be displayed inside the video image.
Display Text
When checked, inputted text on “OSD Test” will be displayed on the video
image.
OSD Date Format
OSD Date format, choose based on user preference.
