P a g e | 52

GDS3710 User Manual

Version 1.0.7.8

GDS3710 HOME WEB PAGE

Once logged in successfully to the GDS3710, user will see the following page.

Note: the options displayed might differ from browser to another.

Figure 35: Home Page: Internet Explorer 11

Table 5: Home Page Description

Number

Fields

Description

LiveView

Access to live view stream page.

Door System

Settings

Access to “Door System Settings” page.

System Settings

Access to “System Settings” page.

Account

Access to “Account” configuration page.

Phone Settings

Access to “Phone Settings” configuration page.
