GDS3710 User Manual

Version 1.0.7.8

Figure 96: Network Info Page

Table 38: Network Info

MAC Address

Displays the GDS3710 MAC Address.

IP Address Mode

Displays the IP address mode used.

IP Address

Displays the IP address of the GDS3710.

Subnet Mask

Displays the Subnet Mask used.

Gateway

Displays the GDS3710 Gateway.

DNS Server 1

Displays the Preferred DNS Server.

DNS Server 2

Displays the secondary DNS Server.
