P a g e | 127

GDS3710 User Manual

Version 1.0.7.8

GDS3710 HTTP API

Grandstream Door System supports HTTP API (Application Programming Interface).

For more details, please refer to following guide:

http://www.grandstream.com/sites/default/files/Resources/gds37xx_http_api.pdf

The document explains in detail the external HTTP-based application programming interface and

parameters of functions via the supported method. The HTTP API is firmware dependent. Please refer to

the related firmware Release Note for the supported functions.

Administrator P

rivilege is required, and administrator authentication verification has to be executed

before any operation to the related parameter configuration.

Table of Contents6
