P a g e | 126

GDS3710 User Manual

Version 1.0.7.8

CONNECTING GS WAVE WITH GDS3710 DOOR SYSTEM

The GDS3710 Door System can interact with the GS Wave softphone application to allow users to open

door, initiate call to the GDS3710, offering more mobility during security monitoring and increasing

connectivity to essential communications and real-time audio/video stream.

- GS Wave Android: For more details about needed steps for configuring the GDS3710 to connect

with Grandstream Wave Android™ version, please refer to following guide:

http://www.grandstream.com/sites/default/files/Resources/Connecting_GDS3710_with_GS_Wave_Androi

d_Guide.pdf

- GS Wave IOS: For more details about needed steps for configuring the GDS3710 to connect with

Grandstream Wave iOS™ version, please refer to following guide:

http://www.grandstream.com/sites/default/files/Resources/Connecting_GDS3710_with_GS_Wave_iOS_G

uide.pdf
