Grandstream Networks GDS3710 User Manual

P a g e | 83
GDS3710 User Manual
Version 1.0.7.8
• If the GDS3710 is behind SOHO (Small Office Home Office) router with port forwarding configured
for remote access, static IP should be used to avoid IP address changes after router reboot.
• TCP port above 5000 is suggested to Port forward HTTP for remote access, due to some ISP would
block port 80 for inbound traffic. For example, change the default HTTP port from 80 to 8088, to
make sure the TCP port will not be blocked.
• In addition to HTTP port, RTSP port is also required to configure via port forwarding, so that the
remote party can view the video stream.
• If the default TCP port 80 is changed to port “A”, then RTSP port should be “2000+A” (changed
from default TCP 554). Both TCP port “A” and “2000+A” should be configured for port forwarding
in the router. For example, of the HTTP port is changed to 8088, the RTSP port should be 10088,
both TCP ports 8088 and 10088 should be configured for port forwarding to have remote GDS3710
access: 8088 for web portal, and 10088 for video streaming.
Access Settings
This page configures the GDS3710 access control parameters.
Figure 63: Access Settings Page
Table 13: Access Settings
Web Access Mode
Selects the access mode to the webGUI either HTTP or HTTPS.
Web Access Port
Specifies the TCP port for Web Access, default 443.
