GDS3710 User Manual
Version 1.0.7.8
Triggered upon events, sent via email and/or FTP.
High-performance streaming server allowing multiple simultaneous accesses:
• Primary video stream: 1920 x 1080 resolution for continuous full HD recording.
• Secondary video stream: 640 x 480 resolution for SIP/VoIP video calls.
• Third video stream: 320 x 240 resolution for smartphone Apps.
TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS local upload and mass provisioning using
TR-069 (pending), ARP/RARP, ICMP, DNS, DHCP, SSH, SMTP, TFTP, NTP,
STUN, TLS, SRTP.
Broad interoperability with most 3rd party SIP/VoIP devices and leading
SIP/NGN/IMS platforms.
G.711µ/a-law, G.722, G.729A/B, DTMF (RFC2833, SIP INFO), AEC.
Layer 2 QoS (802.1Q, 802.1P) and Layer 3 QoS (ToS, DiffServ, MPLS).
User and administrator level access control (pending), MD5 and MD5-sess based
authentication, 256-bit AES encrypted configuration file, TLS, SRTP, HTTPS,
802.1Q.
Firmware upgrade via TFTP/HTTP/HTTPS, mass provisioning using TR-069
(Pending) or AES encrypted XML configuration file.
Built-in Digital Microphone, up to 1.5m with AEC.
Built-in HD Loudspeaker (2 Watt), sound quality suitable for up to 3 m.
12-key touchpad plus a capacitive doorbell button, each with individual LED
illumination.
125KHz: EM4100 (1 RFID card and 1 RFID key fob included).
Yes, 2 channels, Vin < 15V, for door sensor or other devices.
Yes, 2 channels, 125VAC/0.5A, 30VDC/2A, Normal Open or Normal Close, for
electric lock, light switch or other devices.
Wiegand (26 bits) input and output.
173mm(H) x 80mm(W) x 36mm(D).
0.6 Kg.
PoE (Power over Ethernet) IEEE 802.3af Class 3, or 12VDC/1A connection (AC
power adapter not included).
Weather proof, vandal resistant, with support for extra back reinforcing metal plate
Operation: -30°C to 60°C (-22°F to 140°F)
Storage: -35°C to 60°C (-31°F to 140°F)
