FC4200-UM-251-03-9370 26
REPLACEMENT PROCEDURES
6.16 Setting the Origin Position (FC4200-60)
Adjust the drawing origin to a position (87 mm, 20 mm) from the left edge of the XR rail.
To set the origin (or home position), follow the procedure in Section 7.8, “Adjusting the Home Position.”
