FC4200-UM-251-03-9370 72
PART LIST
11. PART LIST
11.1 Recommended List of Parts
Part No. Description Name Remarks
772219580 4200 Main Board
772219530 4200 Pen Board FC4200-50, FC4200-60
772121520 4210 Pen Board FC4210-60
792219701 Pen Block FC4200-50, FC4200-60
792121701 4210 Pen Block Assy FC4210-60
772219510 4200 Relay
772219520 4200 Mark Sensor Assy FC4200-50, FC4200-60
772121530 4210 Mark Sensor Assy FC4210-60
500050535 KR1228 Mark Sensor
772219500 4200 X Sensor
370801091 X Drive Belt Belt 120S2M160U
622190411 Y Slide Belt 4250 Y Belt 4250 FC4200-50
622191411 Y Slide Belt 4260 Y Belt 4260 FC4200-60, FC4210-60
618122100 X Intermediate Pulley X Intermediate Pulley 60
622190130 X Tension Pulley X Tension Pulley
622190151 Pulley S2M-Z30 Pulley S2M-Z30
622190401 X Belt 4250 X Belt 4250 FC4200-50
622191401 X Belt 4260 X Belt 4260 FC4200-60, FC4210-60
622190140 P4 Y Tension Pulley P4 Y Tension Pulley
622190350 Inertia Pulley Z24 Inertia Pulley Z24
500050538 4200 Fan TUDC24B4-602
772219560
4200 Control Panel Relay Board
Control Panel Relay Board
772219600 4250 Elect-static Panel SW FC4200-50
622190490 Pen Sense Rubber FC4200-50, FC4200-60
772219550 Operation Sheet (domestic)
622190420 Inertia Wheel Inertia 42
500001803 LCD Unit GX3
122527140 Y Flex Cable FCA2252014 FC32
775421810 X Motor FP90
775421830 Y Motor FP90
691800520 X Flex Cable A1 FPC,06710 FC4200-60, FC4210-60,FP91
691800530 X Flex Cable A2 FPC,67110 FC4200-50, FP92
775421740 High Voltage Unit FC4200-50, FP90
510000051 Power Supply Unit PS089B DX10
054112100 20Z Pulley 14 FP61
772160580 Y Drive Pulley FC21
379500004 Y Drive Belt 100TN15-10W GX10
035132220 P Deenergize Brush MP50
054212140 Wiper FP80
054212201 L Roller S FP80
054212211 L Roller L FP80
054212221 L Roller SC FP80
054212231 L Roller LC FP80
095013010 Roller BB13 GX10
031009020 Positioning Seal MP30
508000025 Power Supply SW JWA2120-0033 3120
313068820 Roller B 688ZZNRAV2S
To Next Page
