FC4200-UM-251-03-9370 32
REPLACEMENT PROCEDURES
6.22 Pen Sense Rubber Pasting Position (FC4200-50 / -60 only)
Paste (1) Pen Sense Rubber at the position shown below.
32
2.525
(
2.5
)
The pasting position is accepted
if the pen is within the hatched
section of the rubber.
