FC4200-UM-251-03-9370 59
TROUBLE SHOOTING
9.4 General Error Messages
Error message Cause Solution
[X POSITION ALARM POWER OFF
THEN ON]
or
[Y POSITION ALARM POWER OFF
THEN ON]
The cutting conditions specified
for the medium to be cut are
unreasonable.
Lower the SPEED setting. Lower the
FORCE setting.
Something is obstructing the pen
carriageʼs movement.
After removing the obstacle, turn the
plotter off then back on again.
An external load was applied to
the pen carriage during operation.
After removing the obstacle, turn the
plotter off then back on again.
Fragments of the cut medium have
entered into the plotterʼs moving
parts and are impeding their
movement.
After removing the obstacle(s), turn the
plotter off then back on again.
• The beeper sounds.
• The PROMPT lamp lights.
The table of acceleration rates is
faulty.
Replace the X motor or the Y motor.
Replace the main board.
To Next Page
