FC4200-UM-251-03-9370 75
PART LIST
11.3 Main Frame, X Slide Section, and X Drive Section
No. Part No. Description Name Remarks Qʼty
1 775421810 X Motor X Motor FP80 1
2 691800530 X Flex Cable Section A2 FPC, 06711 FC4200-50, FP92 1
691800520 X Flex Cable Section A1 FPC, 06710 FC4200-60, FC4210-60, FP91 1
3 054220010 Honeycom board A2 Honeycom board FC4200-50, FP82 1
022552120 Honeycom board Honeycomb Panel 3260 FC4200-60, FC4210-60, 3260 1
4 771805000 Elect-static Adhesion Panel 92 Elect-static Panel FC4200-50, FP92 1
022552010 Writing Panel PV Panel 92x66 FC4200-60 1
621210100 Writing Panel PV Panel 4210 FC4210-60 1
5 054112100 X Motor Pulley 20Z Pulley 14 FP61 1
6 313068820 Roller B 688ZZNRAV2S 5
7 618122100 X Intermediate Pulley 60 X Intermediate Pulley 60 1
8 622190130 X Tension Pulley X Tension Pulley 2
9 622190151 Pulley S2M-Z30 Pulley S2M-Z30 2
10 370801091 X Drive Belt Belt 120S2M160V 1
11 622190401 X Slide Belt X Belt 4250 FC4200-50 2
622191401 X Slide Belt X Belt 4260 FC4200-60, FC4210-60 2
12 035132220 Anti-static Brush P Anti-static Brush Brush MP50 1
13 054212140 Wiper Wiper FP80 4
14 054212201 Roller S Roller S 4
15 054212211 Roller L Roller L 2
16 054212221 Roller SC Roller SC 2
17 054212231 Roller LC Roller LC 1
18 308002001 Tape Measure Measure ST13-01BP 1
19 772219500 X Sensor Board Assy 4200X Sensor 1
19-1 508000005 X Home Sensor SW, GP1A52HR 1
20 621212000 X Rear Slider Base X Rear Slider Base RK FC4210-60 1
21 621212030 Applying Plate Applying Plate FC4210-60 1
22 621212020 Block Block FC4210-60 1
23 054212240 Vertical Tension Plate V Plate FC4210-60 1
24 054212120 Tension Plate Per-Tension Arm H3 FC4210-60 1
To Next Page
