FC4200-UM-251-03-9370 78
PART LIST
11.4 Y Bar, Y Slide Section, Y Drive Section, and Pen Block Section
No. Part No. Description Name Remarks Qʼty
1 775421830 Y Motor Y Motor FP80 1
2 122527140 Y Flex Cable FCA2252014 3250 1
3 772160580 Y Drive Pulley Assembly FC21 1
4 379500004 Y Drive Belt 100TN15-10W GX10 1
5 622190140 P4 Y Tension Pulley 1
6 622190350 Inertia Pulley Z24 1
7 622190420 Inertia 42 1
8 095013010 Roller Roller BB13 GX10 5
9 621113010 BR Tension Plate FC4200-50, FC4200-60, CE10 1
621213000 Y Tension Plate FC4210-60 FC4210-60 1
10 035132220 Anti-static Brush 1
11 322195213 Y End Cover F 1
12 622145202 Y End Cover R 1
13 322190500 Stopper 8mm 1
14 622190091 Y Rail Y Rail FC4200-50 FC4200-50 1
622191091 Y Rail Y Rail FC4200-60 FC4200-60, FC4210-60 1
15 622195031 Y Rail Cover FC4200-50 FC4200-50 1
622195531 Y Rail Cover FC4200-60 FC4200-60, FC4210-60 1
16 622190411 Y Belt Y Belt FC4200-50 FC4200-50 1
622191411 Y Belt Y Belt FC4200-60
FC4200-60, FC4210-60 1
17 622192130 Mark Sensor Base Braket Mark Sensor Base FC4200-50, FC4200-60 1
621213100 Mark Sensor Base Braket Mark Sensor Base FC4210 FC4210-60 1
18 095004130 MC Insulating Collar FC4200-50, FC4200-60 2
095004130 MC Insulating Collar FC4210-60 4
19 095704040 Insulating Sheet B FC4200-50, FC4200-60 1
095704040 Insulating Sheet B FC4210-60 2
20 617363321 LB4YC Assembly FC4200-50, FC4200-60 1
621214000 LM6L Assembly FC4210-60 2
21 619003360 Bearing Roller Base BR Base FC4200-50, FC4200-60 1
621214051 Bearing Roller Base B BR Base Bracket FC4210-60 1
621214060 Bearing Roller Base BR Base FC4210-60 2
22 617363351 Pen Encoder Strip FC4200-50, FC4200-60 1
617363351 Pen Encoder Strip FC4210-60 2
23 619003371 Offset Pin Shaft FC4200-50, FC4200-60 Only 1
24 619004011 Carriage Cover FC4200-50, FC4200-60 1
621216000 Carriage Cover FC4210-60 FC4210-60 1
25 310068320 Bearing Roller 683ZZMC3PS2S FC4200-50, FC4200-60 2
310068320 Bearing Roller 683ZZMC3PS2S FC4210-60 4
26 617363390 Guide Shaft FC4200-50, FC4200-60 1
617363390 Guide Shaft FC4210-60 2
27 380205381 Tension Spring E-538 FC4200-50, FC4200-60 1
380205551 Tension Spring E-555 FC4210-60 2
621214070 Spring Bracket FC4210-60 1
28 622192050 Moving Coil Base MC Base 42 FC4200-50, FC4200-60 1
621214010 Moving Coil Base MC Base 4210 FC4210-60 1
29 622192040 Pen Arm 42 FC4200-50, FC4200-60 1
621214020 Pen Arm 4210 FC4210-60 2
30 053203420 Magnet FC4200-50, FC4200-60 2
31 622192012 Cutter Holder A FC4200-50, FC4200-60 1
021500631 Cutter Holder FC4210-60 2
32 622192022 Cutter Holder B FC4200-50, FC4200-60 1
621214100 Cutter Pen Stopper FC4210-60 2
33 622192060 Pen Holder AP FC4200-50, FC4200-60 2
34 622192071 Lock Arm FC4200-50, FC4200-60 2
To Next Page
