9.3.3 Error Messages in HP-GL Command Mode
If any of the HP-GL command error messages listed in the following table is displayed, the cause can
nearly always be traced to one of the causes below:
(1) The software application’s output device setting has changed; or
(2) The plotter’s interface conditions have changed.
If a command error occurs while the COMMAND setting is HP-GL, therefore, first check the two corre-
sponding points below.
(1) Configure the software to drive your plotter and ensure that the software’s interface conditions are
correctly set; and
(2) Re-specify the plotter’s interface conditions.
Solution
Issue a command that the plotter
will recognize.
Re-issue the command with the
correct number of parameters.
Re-issue the command with its
parameters specified within their
permissible ranges.
Specify a character set that the
plotter will recognize.
Issue the command with its coor-
dinate data specified within the
effective cutting/plotting area.
Increase the buffer size.
Check the programmed data.
Check the programmed data.
Check the programmed data.
Check the programmed data.
Check the programmed data.
Check the settings of the RS-232C
interface conditions.
Check the settings of the RS-232C
interface conditions.
Error message
ERROR 1
Instruction not recognized
ERROR 2
Wrong number of parameters
ERROR 3
Out of range parameters
ERROR 5
Unknown character set
ERROR 6
Position overflow
ERROR 7
Buffer overflow
ERROR 10
Invalid I/O output request
ERROR 11
Invalid byte following ESC
ERROR 12
Invalid byte in I/O Control
ERROR 13
Out of range I/O parameter
ERROR 14
Too many I/O parameters
ERROR 15
Error in I/O transmission
ERROR 16
I/O buffer overflow
Cause
An unrecognizable command was
issued.
A command was issued with the
wrong number of parameters.
A command containing an invalid
parameter was issued.
An unknown character set was
specified.
A command was issued with coor-
dinate data that exceeds the effec-
tive cutting/plotting area.
The data being input exceed the
capacity of the downloadable char-
acter buffer, polygon buffer, etc.
While executing an output com-
mand, the plotter received another
output command.
Receipt of the ESC character was
followed by an invalid byte.
A device control command con-
taining an invalid byte was received.
An I/O control command was is-
sued with parameter outside of the
permissible numeric range.
An I/O control command was is-
sued with too many parameters.
During data transfer, a framing error,
parity error, or overrun error oc-
curred.
The I/O buffer received data faster
than it could process the data.
