Gtec SATURN - Battery Charger; Dimensions and weight; Modes and efficiency values; Miscellaneous

- 115 -
CPS Models
CPS 6
CPS 10
CPS 15
Dimensions and weight
W x D x H
440 x 850 x 1320 mm
Weight without batteries
105 Kg
110 Kg
120 Kg
Weight with batteries
315 Kg
320 Kg
Modes and efficiency values
Operating modes
ON LINE
ECO
EMERGENCY ONLY
AC/AC efficiency in on line mode
93.5%
93.5%
94%
AC/AC efficiency in Eco mode
98%
DC/AC efficiency in autonomy mode
≥92.5%
≥92.5%
≥93.5%
Miscellaneous
Noise
≤ 48dB(A)
≤ 48dB(A)
≤ 52dB(A)
Color
RAL 7016
Ambient temperature
(6)
0 – 40 °C
(1)
To maintain the output voltage within the range of precision indicated, it may have to be recalibrated after a long period of operation
(2)
If the mains frequency is within ± 5% of the selected value, the CPS is synchronized with the mains. If the frequency is outside the
tolerance limits or running on the battery, the frequency is the value selected +0.1%
(3)
Mains/Battery @ load 0% -100%
(4)
@ Mains / battery / mains @ resistive load 0% / 100% / 0%
(5)
The recharging current is regulated automatically according to the capacity of the battery installed
(6)
20 – 25 °C for maximum battery life
(7)
@ 100% load & THDv ≤ 1%
Battery Box
BBX 1320 480V
BB NP T4 3F
BBX 1320 480V
BB NP T2 3F
BBX 1320 480V
BB NP T5 3F
Battery
Rated voltage per branch
240 Vdc
No. batteries / V / Ah
80 / 12 / 9
120 / 12 / 7
120 / 12 / 9
Miscellaneous
Ambient temperature
(1)
0 – 40 °C
Humidity
<95% non-condensing
Protective devices
Overcurrent – Short circuit
W x D x H
400 x 815 x 1320 mm
Weight
300 Kg
390 Kg
400 Kg
(1)
20 – 25 °C for maximum battery life
