ALL THE OPERATIONS DESCRIBED IN THIS SECTION ARE TO BE PERFORMED EXCLUSIVELY BY
QUALIFIED STAFF.
The company declines all liability for damage caused by incorrect connections or operations not
described in this manual.
STORING THE CPS AND THE BATTERY BOX
The storage room must respect the following conditions:
PREPARING FOR INSTALLATION
PRELIMINARY INFORMATION
Max. relative humidity during operation
Max. height of installation
1000 m at rated power
(-1% Power for every 100 m above 1000 m)
max 4000 m
Power dissipated at rated resistive load
(pf=0.9) and with battery as buffer *
0.47 kW
404 kcal/h
1603 B.T.U./h
0.63 kW
540 kcal/h
2150 B.T.U./h
0.86 kW
740 kcal/h
2940 B.T.U./h
Power dissipated at rated distortion
load (pf=0.7) and with battery charged *
0.37 kW
318 kcal/h
1263 B.T.U./h
0.49 kW
420 kcal/h
1670 B.T.U./h
0.67 kW
580 kcal/h
2290 B.T.U./h
Flow rate of fans for removing heat from
installation room **
Current leak to earth ***
* 3.97 B.T.U./h = 1 kcal/h
** The following formula can be used to calculate the fan capacity: Q [mc/h] = 3.1 x P
diss
[kcal/h] / (t
a
- t
e
) [°C]
P
diss
is the dissipated power of all the installed apparatus at the installation premises expressed in kcal/h.
ta= environmental temperature, te= external temperature. To account for leaks, increase the value obtained by 10%.
The table shows an example of the fan capacity with (t
a
- t
e
)=5°C and with nominal resistive load (pf=0.9).
(N.B.: The formula applies if ta>te; otherwise an air conditioner should be installed).
*** The dispersion current of the load is added to the dispersion current of the CPS on the earth protection conductor.
