APS-7000 Series User Manual
102
Manage Preset Settings
Preset settings can be easily saved to or from a USB flash drive
using the Save/Recall Files utility in the Menu system. Files can
also be deleted from local memory using the utility.
File Format
When files are saved to USB they are saved in
the following format:
presetX.set, where X is the memory number
M0 ~ M9. The files are saved to USB:/gw.
When files are recalled from USB, files must be
recalled from the same memory number. For
example, the file preset0.set can only be recalled
to memory number M0. The files can only be
recalled from the USB:/gw directory.
Steps
1. Press the Menu key. The Menu
settings will appear on the
display.
Menu
2. Use the scroll wheel to go to item 12,
Save/Recall Files and press Enter.
3. Go to the Type setting using the scroll wheel
and press Enter. Select Preset and press Enter to
confirm.
4. Go to the Action setting and choose the file
operation and then press Enter.
MEMUSB
Saves the selected preset
memory from the local memory
to a USB flash drive.
MEMUSB
Loads a preset memory from a
USB flash drive to the selected
local memory.
DELETE(MEM)
Deletes the selected preset
memory from local memory.
