GW Instek APS-7000 Series User Manual

APPENDIX
181
APS-7000 Specifications
The specifications apply when the APS-7000 is powered on for at
least 30 minutes. Note that the high frequency and high voltage
options are listed as separate specifications.
Standard APS-7000
Model
APS-7050
APS-7100
APS-7200
APS-7300
AC Input
Phase
Single Phase
Voltage
115/230 Vac ± 15%
230 Vac ± 15%
Frequency
50/60 Hz
Max. Current
16A/8A
32A/16A
32A
50A
Power Consumption
1.8 kVA or
less
3.6 kVA or
less
7.2 kVA or
less
10.8 kVA or
less
Power Factor
0.7 Typ.
AC Output
Power Rating
500 VA
1000 VA
2000 VA
3000 VA
Output Voltage
0 ~ 155Vrms / 0 ~ 310.0 Vrms
Output Frequency
45.00 ~ 500.0 Hz
Maximum Current (r.m.s)
*1
0 ~ 155 Vrms
4.2 A
8.4 A
16.8 A
25.2 A
0 ~ 310 Vrms
2.1 A
4.2 A
8.4 A
12.6 A
Maximum Current (peak)
0 ~ 155 Vrms
16.8 A
33.6 A
67.2 A
100.8 A
0 ~ 310 Vrms
8.4 A
16.8 A
33.6 A
50.4 A
Phase
Single Phase, Two Wire (1P2W)
Total harmonic distortion
(THD)
*2
≤ 0.5% at 45 ~ 500Hz (Resistive Load)
Crest factor
≧4
Line regulation
0.1% (% of full scale)
Load regulation
0.5% (% of full scale)
Response time
< 100µS
Reverse current
30% of Maximum Output RMS Current
(Continue)
100% of Maximum Output RMS Current (Within 3
minutes)

GW Instek APS-7000 Series Specifications

General

Brand	GW Instek
Model	APS-7000 Series
Category	AC Power Distribution
Language	English
