GW Instek APS-7000 Series User Manual

APS-7000 Series User Manual
182
Model
APS-7050
APS-7100
APS-7200
APS-7300
Setting
Voltage
Range
0 ~ 155 Vrms, 0 ~ 310 Vrms, Auto
Resolution
0.01 V at 0.00 ~ 99.99 Vrms
0.1 V at 100.0 ~ 310.0 Vrms
Accuracy
± (0.5% of setting + 2 counts)
Frequency
Range
45 ~ 500 Hz
Resolution
0.01 Hz at 45.00 ~ 99.99 Hz
0.1 Hz at 100.0 ~ 500.0 Hz
Accuracy
± 0.02% of Setting
Power on/off phase angle
Range
0 ~ 359°
Resolution
1°
Accuracy
± 1° (only 45 ~ 65 Hz)
Measurement
*3
Voltage (r.m.s)
Range
0.20 ~ 38.75 Vrms
38.76 ~ 77.50 Vrms
77.51 ~ 155.0 Vrms
155.1 ~ 310.0 Vrms
Resolution
0.01 V at 0.00 ~ 99.99 Vrms
0.1 V at 100.0 ~ 310.0 Vrms
Accuracy
*4
± (0.5% of reading + 2 counts)
Frequency
Range
45 ~ 500 Hz
Resolution
0.01 Hz at 45.00 ~ 99.99 Hz
0.1 Hz at 100.0 ~ 500.0 Hz
Accuracy
± 0.1 Hz
Current (r.m.s)
Range
2.00 ~ 70.00 mA
60.0 ~ 350.0 mA
0.300 ~ 3.500 A
3.00 ~ 17.50 A
0.200 ~ 3.500 A
3.00 ~ 35.00 A
Resolution
0.01 mA
0.1 mA
0.001 A
0.01 A
0.001 A
0.01 A
Measurement continued next page.
