GW Instek APS-7000 Series - Sequence Settings

APS-7000 Series User Manual
130
Sequence Settings
Entering the
Sequence Menu
1. Press Test.
Test
2. Press Mode[F1] and use the scroll wheel to
display Sequence Mode and then press Enter.
Sequence Mode
F1 MODE
Voltage range
Steps
3. Use the scroll wheel to go to the Step setting
and press Enter.
4. Use the scroll wheel to select the step number.
0 is always the starting step for the sequence.
Step
0 ~ 255
5. Go to the Time setting and set the duration of
the step.
Time
0.01 ~ 999.99s
6. Go to the Jump To setting and choose which
step to jump to, or turn the setting off.
Step
ON, OFF, 0 ~ 255
7. Go to the Jump Cnt setting and set the number
of times the current step will loop.
