GW Instek APS-7000 Series User Manual

OPERATION
129
Voltage
Range
There are 4 voltage range settings:
HI range (0~600VAC), MD range
(0~310VAC), LO range (0~
155VAC), Auto
Fset
Sets the frequency of the step.
Sequence
Example
Time of step Time of next step
ON Phs
completion time
ON Phs
ON
Phs
Step 1
Jump Cnt=0
Step 1
Jump Cnt=1
Time of step
Output off
OFF Phs
Sequence Flow
Example
Step 1
Jump To
Branch 1
Go to StepX
Go to StepX
Cnt > 0
Branch 2
Jump to StepX
On
Off
On
Off
On
Off
Jump Cnt
On
Off
Go to the next
step
Term
END
CONTI
HOLD
Stop test
Wait for
user input
Jump Cnt
Cnt = 0
Step 0
