GW Instek APS-7000 Series User Manual

OPERATION
31
Filter Installation
Background
The APS-7200/7300 has a filter (GW Instek part
number, 57RG-30B01801) that must first be
inserted under the control panel before
operation.
Steps
1. Pull outward as indicated
in the arrow to detach the
snap.
See below
for details
2. Remove the cover
3. Remove the screws
4. Move the plastic frame in
the direction indicated by
the arrow
