REAR PANEL SIGNAL OUTPUTS
149
REAR PANEL SIGNAL
OUTPUTS
The rear panel has 3 signal output connectors.
These connectors are used for external triggering,
synchronization and test judgment state. The
following chapter will give a brief overview each
of these connectors.
J1 Connector Overview ................................................................ 150
Signal Output Overview ............................................................... 151
SYNC Output Overview .............................................................. 152
