OPERATION
105
ARB Mode Overview
Background
The ARB mode function has 7 basic waveforms
and a number of settable attributes, depending
on the chosen waveform.
Setting Screen
Overview
Waveform
type
Attributes for the
selected waveform
Visual representation
of the waveform shape
and its attributes
F4 Exit
ARB Waveform
Overview
The following describes each of the 7 basic
waveforms.
Sine
This is the default waveform used for
the APS-7000. No settable attributes.
