APS-7000 Series User Manual
122
Manage Simulation Settings
Simulation settings can be easily saved to or from a USB flash drive
using the Save/Recall Files utility in the Menu system. Files can
also be deleted from local memory using the utility.
File Format
When files are saved to USB they are saved in
the following format:
simX.sim, where X is the memory number
0 ~ 9 (SIM0 ~ SIM9). The files are saved to
USB:/gw.
When files are recalled from USB, files must be
recalled from the same memory number. For
example, the file sim0.sim can only be recalled
to memory number SIM0. The files can only be
recalled from the USB:/gw directory.
Steps
1. Press the Menu key. The Menu
settings will appear on the
display.
Menu
2. Use the scroll wheel to go to item 12,
Save/Recall Files and press Enter.
3. Go to the Type setting using the scroll wheel
and press Enter. Select SIMULATE and press
Enter to confirm.
4. Go to the Action setting and choose the file
operation and then press Enter.
MEMUSB
Saves the selected simulation
memory from the local memory
to a USB flash drive.
MEMUSB
Loads the simulation memory
from a USB flash drive to the
selected local memory.
