APS-7000 Series User Manual
110
6. Set the voltage, frequency, Irms
level and so on as you normally
would for the standard ACV
output. See the Basic Operation
chapter for setting details.
Page 60
Note
When the WAVE parameter is set to any waveform
other than SINE, ARB will be shown on the display
when in the BASIC operation, Simulate mode or
Sequence mode to indicate that the ARB function
is active when in these modes.
Standard Mode
Example
Simple Mode
Example
Sequence
Example
