APS-7000 Series User Manual
152
CAUTION
The internal relays allow for a maximum voltage of
250VAC and maximum current of 3A.
SYNC Output Overview
Overview
The SYNC output outputs a +10V signal when
the output is turned on.
Pin Assignment
SYNC
GND
SYNC output
