GW Instek APS-7000 Series User Manual

OPERATION
53
Using the
onscreen
keyboard
The onscreen keyboard is only used in the
Program Mode. The screenshot below is an
example of the onscreen keyboard.
On screen keyboard
Entered characters
Using the
Function Keys
The function keys are quick settings keys, the
function of which depends on the current
menu or operation.
1. Press the function key that corresponds to the
setting directly to its left.
2. The setting or parameter is immediately
executed.
Function keys
APS-7050
AC Power Source
Display
Programmable
Output
: Long Push
Menu Test Preset
V
Local
Off Phase
On Phase
0
1
4
7
2
5
8
3
6
9
V-Limit F-Limit IPK-Limit
F I rms
Cancel
Shift
Range
Enter
Lock
ALM CLR
IPK CLR
Unlock
Surge / Dip
Ramp
TriggerARB
F 1
F2
F3
F4
Corresponding quick
settings
3. Repeat the steps above for all the relevant
digits.
