APS-7000 Series User Manual
86
3. Go to the Mode setting using the scroll wheel
and press Enter. Select either Voltage or Time
and press Enter again to confirm.
Mode
Voltage, Time
4. For Voltage mode, set Vup and Vdn.
Vup
0.01 ~ 99.99Vrms
Vdn
0.01 ~ 99.99Vrms
5. For Time mode, set Tup and Tdn.
Tup
0.1 ~ 999.9ms
Tdn
0.1 ~ 999.9ms
Exit
6. Press Exit[F4] to exit from the
Ramp Control settings.
7. Upon exiting the ramp icon will
appear in the status bar.
