H3C S5100-SI

1-11
802.1p precedence
value
Target local precedence
value
Target DSCP value
1 0 0
2 0 8
3 1 24
4 2 32
5 2 40
6 3 48
7 3 56
Table 1-8 The default DSCP -to-other-precedence mapping table of S5100-EI series
switches
DSCP values
Target local
precedence value
Target drop
precedence value
Target 802.1p
precedence value
0 to 7 0 1 1
8 to 15 1 1 2
16 to 23 2 1 0
24 to 31 3 1 3
32 to 39 4 0 4
40 to 47 5 0 5
48 to 55 6 0 6
56 to 63 7 0 7
Table 1-9 The default DSCP-precedence-to-other-precedence mapping table of S5100-SI
series switches
DSCP values
Target local precedence
value
Target 802.1p
precedence value
0 to 7 0 1
8 to 15 0 2
16 to 23 1 0
24 to 31 1 3
32 to 39 2 4
40 to 47 2 5
48 to 55 3 6
56 to 63 3 7
