 Note:
z The rmon alarm and rmon prialarm commands take effect on existing nodes only.
z For each port, only one RMON statistics entry can be created. That is, if an RMON statistics
entry is already created for a given port, you will fail to create another statistics entry with a
different index for the same port.
2.3 Displaying RMON
To do… Use the command… Remarks
Display RMON statistics
display rmon statistics [ interface-type
interface-number | unit unit-number ]
Display RMON history information
display rmon history [ interface-type
interface-number | unit unit-number ]
Display RMON alarm information
display rmon alarm [ entry-number ]
Display extended RMON alarm
information
display rmon prialarm [ prialarm-entry-number ]
Display RMON events
display rmon event [ event-entry ]
Display RMON event logs
display rmon eventlog [ event-entry ]
Available in any
view.
2.4 RMON Configuration Example
1. Network requirements
z The switch to be tested is connected to a remote NMS through the Internet. Ensure that the
SNMP agents are correctly configured before performing RMON configuration.
z Create an entry in the extended alarm table to monitor the information of statistics on the
Ethernet port, if the change rate of which exceeds the set threshold, the alarm events will be
triggered.
2. Network diagram
图2-1 Network diagram for RMON configuration
3. Configuration procedures
# Add the statistics entry numbered 1 to take statistics on GigabitEthernet 1/0/1.
<Sysname> system-view
[Sysname] interface GigabitEthernet 1/0/1
[Sysname-GigabitEthernet1/0/1] rmon statistics 1
[Sysname-GigabitEthernet1/0/1] quit
