H3C S5100-SI

2-7
# Configure GigabitEthernet1/0/3 of Switch A.
[SwitchA] interface GigabitEthernet 1/0/3
[SwitchA-GigabitEthernet1/0/3] port link-type trunk
[SwitchA-GigabitEthernet1/0/3] port trunk permit vlan 101
[SwitchA-GigabitEthernet1/0/3] port trunk permit vlan 201
# Configure GigabitEthernet1/0/10 of Switch B.
[SwitchB] interface GigabitEthernet 1/0/10
[SwitchB-GigabitEthernet1/0/10] port link-type trunk
[SwitchB-GigabitEthernet1/0/10] port trunk permit vlan 101
[SwitchB-GigabitEthernet1/0/10] port trunk permit vlan 201
Configuring a Protocol-Based VLAN
Protocol-Based VLAN Configuration Task List
Complete these tasks to configure protocol-based VLAN:
Task Remarks
Configuring a Protocol Template for a Protocol-Based VLAN Required
Associating a Port with a Protocol-Based VLAN Required
Displaying Protocol-Based VLAN Configuration Optional
Configuring a Protocol Template for a Protocol-Based VLAN
Configuration prerequisites
Create a VLAN before configuring the VLAN as a protocol-based VLAN.
Configuration procedure
Follow these steps to configure the protocol template for a VLAN:
To do... Use the command... Remarks
Enter system view
system-view
—
Enter VLAN view
vlan vlan-id
—
Configure the protocol
template for the VLAN
protocol-vlan [ protocol-index ] { at | ip |
ipx { ethernetii | llc | raw | snap } | mode
{ ethernetii etype etype-id | llc dsap
dsap-id ssap ssap-id | snap etype
etype-id } }
Required
By default, no protocol
template is configured
for the VLAN.
When configuring a protocol template for a protocol-based VLAN, use the at, ip or ipx keyword to
configure a standard template to match AppleTalk, IP, and IPX packets respectively, and use the mode
keyword to configure a user-defined template.
