H3C S5100-SI

2-4
Figure 2-5 HyperTerminal CLI
4) You can then configure the switch or check the information about the switch by executing the
corresponding commands. You can also acquire help by typing the ? character. Refer to related
parts in this manual for information about the commands used for configuring the switch.
Console Port Login Configuration
Common Configuration
Table 2-2 Common configuration of console port login
Configuration Remarks
Baud rate
Optional
The default baud rate is 9,600 bps.
Check mode
Optional
By default, the check mode of the console port is set to
“none”, which means no check bit.
Stop bits
Optional
The default stop bits of a console port is 1.
Console port
configuration
Data bits
Optional
The default data bits of a console port is 8.
AUX user interface
configuration
Configure the
command level
available to the
users logging in to
the AUX user
interface
Optional
By default, commands of level 3 are available to the
users logging in to the AUX user interface.
Make terminal
services available
Optional
By default, terminal services are available in all user
interfaces
Terminal
configuration
Set the maximum
number of lines the
screen can contain
Optional
By default, the screen can contain up to 24 lines.
