H3C S5100-SI

1-35
To do… Use the command… Remarks
Enter Ethernet port
view
interface interface-type
interface-number
—
Configure VLAN
mapping
traffic-remark-vlanid
inbound acl-rule remark-vlan
vlan-id [ all-packet |
tagged-packet |
untagged-packet ]
Required
By default, VLAN mapping is
not configured.
The S5100-EI series switches
do not support the all-packet
keyword or the tagged-packet
keyword.
Configuration example
# Configure VLAN mapping to change VLAN IDs of all the incoming packets from network
segment 10.1.1.0/24 into 1001 on GigabitEthernet 1/0/1 (assume that GigabitEthernet
1/0/1 carries VLAN 2 and is connected to network segment 10.1.1.0/24).
<Sysname> system-view
[Sysname] acl number 2000
[Sysname-acl-basic-2000] rule permit source 10.1.1.0 0.0.0.255
[Sysname-acl-basic-2000] quit
[Sysname] interface GigabitEthernet 1/0/1
[Sysname-GigabitEthernet1/0/1] traffic-remark-vlanid inbound ip-group 2000
remark-vlan 1001
Configuring Queue Scheduling
Refer to Queue Scheduling for information about queue scheduling.
Configuration prerequisites
The queue scheduling algorithm to be used and the related parameters have been
determined.
Configuration procedures
1) Configuring SP queuing
Follow these steps to configure SP queuing:
To do… Use the command… Remarks
Enter system view
system-view
—
For S5100-EI series switches:
undo queue-scheduler [ queue-id ]
&<1-8>
Configure SP
queuing
For S5100-SI series switches:
undo queue-scheduler [ queue-id ]
&<1-4>
Optional
By default, SP
queuing is used on all
the output queues of
a port.
