ContentServer 3000
Figure 8–23: ContentServer 3000 Rear Panel
IMPORTANT: Note that, when facing the rear of the chassis, the controller on the left side of the chassis
corresponds to Controller 0 in SystemManager, and the controller on the right side of the chassis
corresponds to Controller 1 in SystemManager.
