ContentStore 3160
Figure 8–35: ContentStore 3160 Front Bezel
Front Panel View
Figure 8–36 and Table 8–35 detail the front view of the ContentStore 3160 with the front bezel
removed and all disk drives in place.
Table 8–34: ContentStore 3160 Front Bezel Components
Component Description
1. Power indicator
A bright blue
power indicator is provided across the top
of the front panel.
2. Air vents Allows airflow through the unit. For optimum airflow, do
not
obstruct the air vents.
2
1
15
OPEN
0
OPEN
14
10
9
3
2
1
4
8
7
5
6
11
12
13
ContentStore 3160
