User Manual
Operation and Management
Page 4-82 (Rev. 4.1/ SW v1.60/ December 2006)
BLANKING MODE
The Blanking Mode parameter sets the display mode of a service when
reception stops.
Blanking Mode
1 Black
2{ Last Field
3{ Last Frame
4{ 75% BAR
5{ Null
The available options are:
• Black – video output signal is a black screen.
• Last Field – video output signal is the last field displayed.
• Last Frame – video output signal is the last frame displayed.
• 75% BAR – video output signal is a colour-bar display.
• Null – video outputs shut down with no output signal.
