PVR 6000 Series
Professional Integrated Receiver Decoders
Page 4-83
TEST MODE
The PVR 6000 can generate a number of Video Test Bars for video quality
testing. All the bars have a full-screen overlay (produced using a Digital
Graphics engine) and are intended for 625 and 525 systems.
Test Mode
1 NULL
2{ VITS PAL LN-17
3{ VITS PAL LN-18
4{ VITS PAL LN-330
5{ VITS PAL LN-331
6{ VITS PAL SPARE
7{ BAR 75%
8{ SIN(X)/X
9{ S/N
10{ SWEEP
11{ SHALLOW RAMP
12{ LUMA RAMP
13{ VITS NTSC LN-17-F1
14{ VITS NTSC LN-17-F2
15{ NTSC YELLOW-RAMP
16{ SECAM 70mV
17{ SECAM 420mV
18{ SECAM 700mV
19{ SECAM ALL
Select from the following Test Bars:
• VITS PAL LN-17 • SHALLOW RAMP
• VITS PAL LN-18 • LUMA RAMP
• VITS PAL LN-330 • VITS NTSC LN-17-F1
• VITS PAL LN-331 • VITS NTSC LN-17-F2
• VITS PAL SPARE • NTSC YELLOW-RAMP
• BAR 75 • SECAM 70mV
• SIN(X)/X • SECAM 420mV
• S/N • SECAM 700mV
• SWEEP • SECAM All
